(32.8ft) LC to SC (UPC) OS2 Single Mode Simplex Fiber Optic Cable

StarTech.com 10m (32.8ft) LC to SC (UPC) OS2 Single Mode Simplex Fiber Optic Cable, 9/125, 40G/100G, Low Insertion Loss, LSZH Jumper Cord
32.8ft LC/SC-UPC Simplex OS2 Single Mode Fiber Cable supports 40G/100G and BiDi; 9/125µm core/cladding; 1260-1625nm Laser Optimized; LSZH jacket w/molded strain reliefs; Bend Radius: 10mm (loaded/unloaded); Insertion/Return Loss: ≤0.3dB/≥55dB

$32.99

Out of stock

SKU: SPSMLCSC-OS2-10M Category:

Description

Manufacturer:

StarTech.com

Manufacturer Part Number:

SPSMLCSCOS210M

Manufacturer Website Address:

http://www.startech.com

Brand Name:

StarTech.com

Product Name:

Fiber Optic Simplex Patch Network Cable

Marketing Information:

OS2 LC to LC Single Mode Simplex Fiber Optic Patch cable facilitates connectivity across 40G/100G networks. It supports Coarse Wavelength Division Multiplexing (CWDM) across an extended wavelength range of 1260-1625nm, improving channel isolation for optimal signal strength over long distances.

Compatibility

Connect to single-fiber networking devices including simplex patch panels, SFP transceivers, and fiber NICs. This 9/125µm OS2 simplex single mode fiber patch cord is backward compatible with OS1 networks, ensuring a reliable connection in legacy fiber environments.

Engineered for Optimal Performance

Precision-manufactured ceramic ferrules ensure accurate fiber alignment for an insertion loss below 0.3dB. Ultra Physical Contact (UPC)-polished LC to LC fiber ends greatly improve return loss characteristics over older PC polishing techniques. The Bend Insensitive fiber core is surrounded by a layer of low refractive index material. This material reduces the amount of light that can escape the fiber cable by reflecting the light back into the fiber. The OS2 fiber patch cord is engineered for low attenuation and performance that exceeds ITU-T G652.D/G657.A1 and IEC60703-2-50 type B1.3/B6.a1 industry standards.

LSZH Cable Jacket

Housed in a Low-Smoke Zero-Halogen (LSZH) flame-retardant jacket, the OS2 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.

Each OS2 fiber cable is individually tested for insertion loss performance and includes a test report, for guaranteed compatibility and 100% reliability.

Packaged Quantity:

1

Product Type:

Network Cable

Cable Type:

Fiber Optic

Cable Characteristic:

Patch Cable

Fiber Optic Mode:

Single-mode

Fiber Type:

Simplex

Core/Cladding Diameter:

9/125 µm

Fiber Category:

OS2

Cable Length:

32.8 ft

Connector Type on First End:

LC Network – Male

Connector Gender on First End:

Male

Connector on First End Details:

1 x LC Network – Male

Connector Type on Second End:

SC Network – Male

Connector Gender on Second End:

Male

Connector on Second End Details:

1 x SC Network – Male

Jacket Type:

LSZH

Device Supported:

  • Network Device
  • Server
  • Switch
  • Storage Device

Data Transfer Rate:

100 Gbit/s

Features:

  • Ultra Physical Contact (UPC)
  • Bend Insensitive
  • Flame Retardant
  • Bend Resistant
  • Passive

Color Family:

Yellow

Product Color:

Yellow

Product Material:

Polypropylene

Jacket Material:

Low Smoke Zero Halogen

Environmentally Friendly:

Yes

Limited Warranty:

Lifetime
